How To Add Route In Linux

In this article, we will learn: Route add command Linux. How to configure static route, and delete temporary and permanent static routes in CentOS/RedHat Linux servers.

Route manipulates the kernel’s IP routing tables. Its primary use is to set up static routes to specific hosts or networks via an interface after it has been configured with the ifconfig program. Route program now is obsolete. The newer version is ip route.

Show Linux Routing Table

Command route -n will show Linux routing table:

route -n

The output of the kernel routing table is organized in the following columns:

Destination
The destination network or destination host.
Gateway
The gateway address or ‘*’ if none set.
Genmask
The netmask for the destination net; ‘255.255.255.255’ for a host destination and ‘0.0.0.0’ for the default route.
Flags
Possible flags include
U (route is up)
H (target is a host)
G (use gateway)
R (reinstate route for dynamic routing)
D (dynamically installed by daemon or redirect)
M (modified from routing daemon or redirect)
A (installed by addrconf)
C (cache entry)
! (reject route)

Also you can use one of the following commands:

# netstat -nr
# ip route list



Add a Temporary Route

For adding temporary static routes in Linux we can use route command. So after system reboot all changes will be lost.

To add a static route for a specific host:

# route add -host 10.110.55.55 gw 10.110.0.2
# route add -host 10.110.55.55 eth0

Delete a static route:

# route del -host 10.110.55.55 eth0



To add a static route for a specific network:

# route add -net 192.168.51.0/24 gw 10.110.0.1
# route add -net 192.168.51.0/24 eth0

Delete a static route for a specific network:

# route add -net 192.168.51.0/24 eth0



Add Permanent Static Route

For add permanent static route, we need to edit the interface file in /etc/sysconfig/network-scripts folder.

Sample configuration for route-eth0 file:

# vi /etc/sysconfig/network-scripts/route-eth0

10.110.0.0/24 via 192.168.0.10 dev eth0



Add Default Gateway Linux CentOS/RedHat

To add Default Gateway:

# route add default gw 10.110.10.1 eth0

To delete default gateway use command route del:

# route del default gw 10.110.10.1 eth0

To set default gateway and make routing changes persistent after reboot we need edit configuration file: /etc/sysconfig/network.

NETWORKING=yes
HOSTNAME=myhost
GATEWAY=10.110.10.1

Save changes end restart networking service:

# service network restart
